Trabant P601 group 2 (1967)

Home » Rally Cars » Trabant P601

Trabant_601.jpg Source

HQM Sachsenring GmbH or VEB Sachsenring
Volkseigener Betrieb (VEB=Publicly Owned Enterprise) Sachsenring Automobilwerke Zwickau
Trabant 601 restoration

Specifications

3096099 units built
Click here and here and here for street version

Group/Class 2 Homologation number: 5142
Years active 1967 - 1995 Homologation start: 1/4/1967
Engine
Type Type P65/66, straight 2 cyl, 2 stoke, petrol engine located front transverse
Capacity 594.5 cc WRC: 594.5 cc
Bore x Stroke (mm) 72.0 x 73.0
Compression ratio 7.6:1
Output power - torgue 23-26 HP / 4000-4200 rpm 5.4 kgm / 2800 rpm
Main bearings split crank with 2 SKF 6009 (d45xD75x16mm) deep groove ball bearings, 33mm big end journals diameter Aluminium alloy piston with 48.6 mm Compression Height
Materials block: cast iron cylinderhead: aluminium alloy cap-heads
Cams/valves 2 inlet ports, 1 exhaust port
Aspiration natural with 1 x BVF 28 HB 2-3 carburetor
Ignition 6V battery, electronic with contact breakers, Firing order 1-2
Cooling system air cooled with 209 mm diameter 9 blades axial fan, guide vanes, thermostat and cut-off air-flaps
Lubrication system Two stroke engine oil MZ-22 in fuel, oil/fuel ratio 1:50
Transmission
Type front wheel drive 4 speed manual gearbox
Gearbox ratios 1st: 4.80/1 (49/12)
2nd: 2.32/1 (44/19)
3rd: 1.52/1 (38/25)
4th: 1.03/1 (31/30)
R: 3.83/1 (46/12)
Diffrential ratio 4.33/1 front differential
Clutch dry, single disk 160 mm diameter
Chassis-body
Type steel monocoque chassis with roll-cage. 2 door saloon Steel frame with Duroplast panels for bodyshell
Front suspension Single transverse leaf spring, lower A-arm, telescopic shock absorbers and anti-roll bar
Rear suspension semi-trailing arm with coil springs, telescopic shock absorbers and anti-roll bar
Steering system rack and pinion (no servo)
Brakes Front rear drums 200mm diameter with 1 double piston caliper front 22 mm, rear 16/19 mm diameter. 1970: 230 mm front drum diameter simplex
Dimensions
length: 3.555 m (139.8 in) width: 1.505 m (50.3 in) height: 1.440 m (56.7 in)
wheelbase: 2.020 m (79.5 in) front track: 1.211 m (47.7 in) rear track: 1.255 m (49.4 in)
Rims - tires steel 4J 13", Bolt pattern 4 x 160mm 145 SR13", 145-75R13
Weight 610kg weight distribution f-r, 45%-55%
Fuel tank 30 lt

Results in WRC

Races

Works team: VEB Sachsenring Automobilwerke Zwickau

Season
Entry Rally event
Driver
Codriver
Team M.C SVE
Entry list
S.R KEN A GRE RAC
Entry list
Eberhard Asmus
Christian Meischner
works 71st
Landgref
Sachse
dnf
Galle
Muler
dnf
Statistics
Others starts/finishes 3/1 3/1

125.jpg Source
Michael Kahlfuss / Ronald Bauer in Monte Carlo '95
ukjESl.jpg Source
T601-6548.jpg Source
engine-small.JPG Source
Trabant%20gross%20%2825%29.jpg?rdrts=52059847 Source
T601-445.jpg Source
Trabant%20gross%20%2816%29.jpg?rdrts=52059925 Source
cb9804e34dfbbf8a50c39c900b98 Source
Front suspension

Drawings

trabant.jpg Source
trabant_601-40922.jpg Source
trabant-601-cut-away.jpg Source

Engine

Motor-1-1.gif Source
Kurbelwelle-1-1.gif Source

Engine compartment underframe

Hilfsrahmen-1-1.gif Source

Headlights

Beleuchtung-1-1.gif Source

Suspension

6820be1b1feca786928c56baecc2f0e2.t00000709_riss.jpg Source
Front suspension
7b6c36d3abbed33f1865a89eb8d8f6ca.t00000344_riss.jpg Source
Front leaf springs
f4bce124cf16e3b007397449879129f0.t00001132_riss.jpg Source
Rear suspension

Chassis

a1fc6785a1bcfe13ada4c70aaae38ede.T00001691-Katalog.jpg Source
