Lister Storm LMP group LMP900 (2003)

Home » Racing Sports Cars » Lister Strom LPM

2003_20_Preliminaires.jpg Source

Specifications

1 unit built
Click here and here

Chevrolet Small Block gen. III LS1 366, V8 (90o) cyl, 4 stroke, petrol engine. Click here for engine tolerances
engine located front longitudinally
5995cc, 106.2 x 84.6 mm
570 bhp / 425 KW @ 6200 rpm
725 Nm / 535 ft lbs @ 5200 rpm
A319 T5 (production) or A357-T6 aluminum alloy block with 234.7mm deck height and 111.8mm bore spacing, A356 T6 aluminium head
nodular iron crankshaft with 5 main bearings 65mm diameter
connecting rod length between centers 155.6mm, big end bearing diameter 53.3mm
camshaft in block with overhead valves (OHV), 2 valves/cyl - 16 valves total
aspiration, natural with multipoint electronic fuel injection
LMP1: 2 x 31.3mm inlet restrictors
firing order 1-8-7-2-6-5-4-3, with Driver side 1 3 5 7, Passenger side 2 4 6 8
water cooled, Reverse flow water cooling
dry sump

Hewland TLS 6 speed manual gearbox, transversely located
limited slip rear differential
carbon fibre composite and aluminium honey-comb monocoque chassis with roll cage. Carbon fibre bodyshell
Front suspension, double wishbones, pull rod operated Eibach coil springs, adjustable Penske dampers and anti-roll bar
Rear suspension, double wishbones, push rod operated Eibach coil springs, adjustable Penske dampers and anti-roll bar
rack and pinion steering
ventilated Hitco carbon disks all around with AP calipers
Length: 4645 mm
Width: 2000 mm
Wheelbase: 2750 mm
910kg


Results in FIA Sport Cars Championship

Season
Car entry, chassis number Car number, result
Estoril Lausirz ring Monza Oschers leben Donington Spa Nogaro
Team 2.5h 2.5h 500km 2.5h 2.5h 1000km 2.5h
Lister Storm Racing, 001 #28, in entry list
Statistics
Works Starts/finishes 0/0

Teams and drivers entries

Results in Endurance races

Team entry, chassis number Car number, result
Daytona Sebring Le Mans Watkins Glen Spa Mont Tremblant Petit Le Mans
Date 2/2 15/3 15/6 22/6 24/8 31/8 21/9 18/10
Duration 24h 12h 24h 6h 500mil 1000km 6h 1600km
Team\ Championship GA RR ALMS GA RR ALMS FIA SC GA RR ALMS
Lister Storm Racing, 001 #6, elec trics #20, acci dent in practice #28, in entry list
Statistics
Works Starts/finishes 2/0 1/0 1/0

Teams and drivers entries


Lister-Storm-LMP_5.jpg Source
2004LM20_car.JPG Source
Lister-Storm_LMP_mp457_pic_39019.jpg Source
