Nissan Datsun Bluebird "U" P610 group 2 (1972)
Home » Rally Cars » Datsun 610
Source
Ove Andersson in Safari rally '72
Source
Ove Andersson in Safari rally '72
Source
Tony Fall in Safari rally '73
Source
Rauno Aaltonen in Safari rally '74
Source | Development chain 1968: Datsun Bluebird 510 1972: Datsun Bluebird 610 1974: Datsun Violet 710 1978: Datsun Violet A10 |
"U" is for "User Oriented"
Specifications
5433 for 160B
Group/Class | 2 | Homologation number: 5434 | |||
Years active | 1972-1974 | Homologation start: 1/1/1972 Homologation end: 31/12/1981 |
|||
Engine | |||||
---|---|---|---|---|---|
Type | Nissan L18, straight 4cyl, 4 stroke, petrol engine | located front longitudinally | |||
Capacity | 1770 cc | WRC: 1770 cc | |||
Bore x Stroke (mm) | 85.0 x 78.0 mm | ||||
Compression ratio | 8.5:1, 9.5:1 | ||||
Output power - torgue | 105 HP @ 6000 rpm 2 carbs: 115 HP @ 6000 rpm inj: 125 HP @ 6200 rpm |
15.0 kgm / 3600 rpm 2 carbs: 15.5 kgm / 4000 rpm inj: 16.0 kgm / 3600 rpm |
|||
Main bearings | 5 of 55mm diameter | connecting rod length between centers 133 mm, big end bearing diameter 50mm, aluminium alloy piston 38 mm compression height | |||
Materials | block: cast iron, 207.85mm deck height (265.9mm from top to bottom oil pan), bore spacing 96.5mm between cylinders 1-2 and 3-4, and 98mm between cylinders 2-3 | cylinderhead: reverse flow cast aluminium alloy with wedge combustion chambers | |||
Cams/valves | single overhead camshaft (SOHC), chain driven | 2 valves/cyl. - 8 valves total. 42mm inlet valves diameter, 35mm exhaust valves diameter. 2 coil springs per valve | |||
Aspiration | natural, 1 x Nihon Kikaki 213304 carburetor, or 2 x Hitachi HJL38W carburetors. 1974: multipoint electronic fuel injection with Bosch electric pump | ||||
Ignition | with contact breakers, firing order 1-3-4-2 | 12V battery | |||
Cooling system | jacketed watercooled with pump, radiator, 330 mm diameter-4 blades fan and thermostat | 6.0 lt | |||
Lubrication system | wet sump | 4.6 lt | |||
Transmission | |||||
Type | rear wheel drive | Nissan 4 speed manual gearbox | |||
Gearbox ratios | constant: 1.409/1 (31/22) 1st: 3.382/1 (36/15) 2nd: 2.013/1 (30/21) 3rd: 1.312/1 (27/29) 4th: 1.000/1 R: 3.365/1 (39/14x18/21) |
constant: 1.409/1 (31/22) 1st: 3.082/1 (35/16) 2nd: 1.857/1 (29/22) 3rd: 1.312/1 (27/29) 4th: 1.000/1 R: 3.365/1 (39/14x18/21) |
group 2: constant: 1.217/1 (28/23) 1st: 2.96/1 (34/14) 2nd: 1.86/1 (29/19) 3rd: 1.31/1 (29/27) 4th: 1.000/1 5th: 0.852/1 (21/30) R: 2.922/1 (36/17x17/15) |
constant: 1.318/1 (31/22) 1st: 3.32/1 (33/14) 2nd: 2.08/1 (28/19) 3rd: 1.31/1 (26/28) 4th: 1.000/1 5th: 0.86/1 (19/30) R: 3.38/1 (36/23x23/15) |
1973: constant: 1.318/1 (31/22) 1st: 2.82/1 (32/16) 2nd: 1.97/1 (28/20) 3rd: 1.47/1 (24/23) 4th: 1.19/1 (22/26) 5th: 1.000/1 R: 3.38/1 (36/23x23/15) |
Diffrential ratio | R160: 3.700 (37/10), 3.900/1 (39/10). 1973: 4.38/1 (35/8), 4.11/1 (37/9), 4.63/1 (37/8) 1976 group 2, R180: 3.15/1 (41/13), 3.36/1 (37/11), 3.55/1 (39/11), 3.700 (37/10), 3.900/1 (39/10), 4.38/1 (35/8), 4.63/1 (37/8), 4.88/1 (39/8), 5.14/1 (36/7) |
Type R180, hypoid spiral bevel gears limited slip rear differential | |||
Clutch | dry single plate, 202mm diameter | ||||
Chassis-body | |||||
Type | steel monocoque Nissan Bluebird 510 chassis with roll-cage. 2 or 4 door saloon steel bodyshell. SSS, Group 2: extended wheel arches and rear spoiler | ||||
Front suspension | Macpherson strut with coil springs, telescopic shock absorbers and anti roll bar | ||||
Rear suspension | semi trailing arm with coil springs, telescopic shock absorbers and anti roll bar | ||||
Steering system | recirculating ball | 3.3 turns lock to lock | |||
Brakes | drums all around 228 mm diameter with 1 double piston caliper 22.2 mm diameter. Front disc brakes 232 mm disc diameter with 1 piston caliper 50.8 mm piston diameter. Group 2: front ventilated disc brake 245 mm diameter with 4 piston caliper 41.3 mm piston diameter | dual circuit with/without vacuum servo assistant | |||
Dimensions | |||||
length: 4.215 m (165.9") | width: 1.600 m (63"), group 2: +100 mm | height: 1.405 m (55.3") or 1.385 m (54.5") | |||
wheelbase: 2.500 m (98.4") | front track: 1.310 m (51.6") | rear track: 1.320 m (52") | |||
Rims - tires | 4.5J x 14" | ||||
Weight | 940 kg | ||||
Fuel tank | 55 lt |
Results in WRC
Races
Works team: Nissan Motor Co
Season
Entry | Rally event | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Driver Codriver |
Team | M.C | SVE | KEN | MAR | GRE | A | S.R | USA | RAC Entry list |
|||||
Ove Andersson John Davenport |
12th | ||||||||||||||
Statistics | |||||||||||||||
Others starts/finishes | 1/1 | 1/1 |
