Daihatsu Charade G100S GT-Ti group A (1988)
 Source |
Development Chain 1984: Daihatsu Charade G11 Turbo 1988: Daihatsu Charade G100S GT-ti |
|
Table of Contents
|
Also called Daihatsu Charade G100S GTxx
Ελληνικό club GTti
English club
Specifications
| Group/Class | A/7 | Homologation number: A5344 |
| Years active | 1988-1993 | Homologation start: 1/1/1988 Homologation end: 31/12/1996 |
| Engine | ||
|---|---|---|
| Type | Daihatsu CB70/CB80, straight 3cyl, 4 stroke | located front transverse |
| Capacity | 993.5 cc | WRC: x 1.7 = 1689cc |
| Bore x Stroke (mm) | 76.0 x 73.0 | |
| Compression ratio | 8.0:1 | |
| Output power - torgue | 120 HP / 6500 rpm (Max 130 HP) | 14.7 kgm (144 Nm) / 3500 rpm |
| Main bearings | 4 of 52mm diameter | connecting rod length 125mm, big end bearing diameter 46mm |
| Materials | block: cast iron 206mm height, fitted with a balance shaft that reduce vibration | cylinderhead: aluminium alloy, 119mm height |
| Cams/valves | 2 overhead camshafts (DOHC), belt driven | 4 valves/cyl. - 12 valves total. 30.2mm inlet valve diameter, 26.2mm exhaust valve diameter. 32.5o angle between inlet valve and vertical, 32.5o angle between exhaust valve and vertical. 1 coil spring per inlet/exhaust valve |
| Aspiration | and (since 1989) IHI RHB5 VQ17 turbocharger (steel heat resistance alloy turbine 50.4mm diameter, aluminium compressor 51mm diameter) with air/air intercooler, Nippon Denso D-jetronic multi point electronic fuel injection | pressure: 1.9 bar |
| Ignition | mapped electronic, firing order 1-2-3 | |
| Cooling system | watercooled | 4 lt |
| Lubrication system | wet sump with oil cooler | 3.5 lt |
| Transmission | ||
| Type | front wheel drive | 5 speed manual gearbox |
| Gearbox ratios | 1st: 3.090/1 (34/11) 2nd: 1.750/1 (35/20) 3rd: 1.230/1 (32/26) 4th: 0.916/1 (33/36) 5th: 0.750/1 (30/40) R: 3.142/1 (30/14 x 44/30) |
1st: 3.090/1 (34/11) 2nd: 2.056/1 (37/18) 3rd: 1.565/1 (36/23) 4th: 1.225/1 (38/31) 5th: 0.891/1 (33/37) R: 3.142/1 (30/14 x 44/30) |
| Diffrential ratio | 4.642/1 (65/14), 4.933/1 (74/15), 5.077/1 (66/13), 5.154/1 (67/13), 5.357/1 (75/14) | helical gears limited slip front differential |
| Clutch | dry single disk 180mm diameter | |
| Chassis-body | ||
| Type | steel monocoque G100S chassis with roll-cage. 3 door hatchback steel bodyshell with polypropylene bumbers | |
| Front suspension | macpherson strut with lower control arm and stabilizer, coil springs and telescopic gas shock absorbers | |
| Rear suspension | macpherson strut with 2 lower transverse and 1 longitudinal arms, coil springs, telescopic gas shock absorbers and anti-roll bar | |
| Steering system | rack and pinion | |
| Brakes | front ventilated disks with 235mm disk diameter and 1 cast iron piston caliper, rear solid disks with 238mm diameter and 1 cast iron piston caliper, or rear drum with 180mm diameter and 25mm width | dual circuit with servo, adjustable ratio split front to rear |
| Dimensions | ||
| length: 3.610 m (142.1 in) | width: 1.615 m (63.6 in) | height: 1.397 m (55.0 in) |
| wheelbase: 2.340 m (92.1 in) | front track: 1.405 m (55.3 in) | rear track: 1.385 m (54.5 in) |
| Rims - tires | 5J x 14", offset ET45, Stud pattern 4x100, Centre bore 56.1mm | 175/60-14 |
| Weight | 760kg | |
| Weight/power | 6.3 kg/HP | |
| Fuel tank | 40 lt | |
| Drag coefficient | 0.32 | |
Results in WRC
Statistics
| 1988 | 1989 | 1990 | 1991 | 1992 | 1993 | 1994 | Total | ||
| Total WRC results | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Races/(A7 wins) | 1/(1) | 1 | 1/(1) | 1/(1) | 1/(1) | 1 | 6/(4) | ||
| Entries/finishes | 3/1 | 1/0 | 2/2 | 1/1 | 3/3 | 1/0 | 11/7 (63.6%) | ||
Races
Works team: -
A/7 classification noted in brackets
| Entry | Rally event | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Driver Codriver |
Team | M.C Entry list |
SVE Entry list |
POR | KEN | TdC | GRE | Oly | (N.Z] | ARG | FIN | (CdI) | S.R | RAC | |
| Manjit Gharial Amolak Hunjan |
Ryce Motors | 12th (2nd) | |||||||||||||
| Ashok Pattni Zahid Mogul |
Ryce Motors | dnf | |||||||||||||
| Sarbi Rai Supee Soin |
dnf | ||||||||||||||
| Statistics | |||||||||||||||
| Starts/finishes | 3/1 | 3/1 | |||||||||||||
Article for production
Click here
SourceMarco Brighetti with Daihatsu Charade GTXX in Safari '93
Source
Source
Drawings
Source
SourceCylinderhead disassembled
Source
