Homologation number: A 5733 (01/01 VR3T)
Homologation start: 1/8/2010
Homologation end: 31/12/2021
Prince PSA EP6CDTS, straight 4 cyl, 4 stroke, petrol engine
1598cc, 77.0 x 85.8 mm
234 HP @ 4750 rpm
430 Nm @ 3000 rpm
aluminium alloy block with 84mm bore spacing, aluminium alloy head
5 main bearings
Double overhead camshaft (DOHC) with BMW Valvetronic variable valve timing (VVT), 4 valves / cyl - 16 valves total
aspiration, 1 x twin-scroll turbocharger with multipoint electronic Direct injection, motorized single throttle valve
Six-speed sequential gearbox, electronically controlled with steering wheel-mounted paddle
Thrust mecanism, 184mm cerametallic twin-disk clutch
ZF limited slip front differential
Front suspension, McPherson type, specific hinges and hub carriers with BOS three-track adjustable shock absorbers (low- and high-speed compression and rebound). Adjustable hydraulic bump stop.
Rear suspension, H-shaped axles with BOS three-track adjustable shock absorbers (low- and high-speed compression and rebound). Adjustable hydraulic bump stop.
Hydraulic power-assisted steering
front Ventilated disks, 330x34mm (tarmac) and 300x30mm (gravel), 4-piston Alcon callipers. Rear 300x8mm discs with 2-piston callipers
length, 3948 mm
width, 1715 mm
wheelbase, 2465 mm
front - rear track, 1520 mm - 1490 mm
wheels, Tarmac 7x17", Gravel and snow 6x15"
tyres, Tarmac Pirelli 200/50 R17, gravel and snow Pirelli 195/70 R15 tyres
1230kg
fuel tank, 67 lt
Results in WRC
Races
Works team: -
| Entry | Rally event | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Driver Codriver |
Team | SVE | MEX | POR | JOR | ITA | ARG | GRE | FIN | DE | AUS | FRA | ESP | GB | ||||
| Harry Hunt Steve McPhee - Robbie Durant |
35th | 21st | mecha nical | dnf | 20th | mecha nical | 24th | |||||||||||
| Paulo Neto Daniel Amaral |
38th | |||||||||||||||||
| Ivo Nogueira Vítor Hugo Oliveira |
P&B Racing | dnf | ||||||||||||||||
| Davide Catania Davide Panu - Fabio Salis |
27th | 38th | ||||||||||||||||
| Michaël Burri Stéphane Rey |
24th | 17th | 27th | |||||||||||||||
| Wolf-Dieter Ihle Reinhard Kessemeier |
36th | |||||||||||||||||
| Martin McCormack David Moynihan |
19th | |||||||||||||||||
| Quentin Giordano Laurent Michon Brunetti |
30th | |||||||||||||||||
| Statistics | ||||||||||||||||||
| Others Starts/finishes | 17/13 | 3/2 | 1/1 | 1/1 | 1/0 | 3/2 | 1/1 | 3/3 | 1/0 | 3/3 | ||||||||
