Abarth Fiat Coupe Zagato Serie IV group GT (1960)
Home » Racing Sports Cars » Abarth Fiat Coupe IV
Fiat_Abarth-front.jpg Source

Chassis types
Bialbero = DOHC

Specifications

Click here and here and here for 1000 Bialbero '60
Click here for 1000 Bialbero 'Long nose' '64
Click here for 1000 SP

Homologation number 82 58 95
Homologation start 20/3/1961 8/3/1960 29/1/1963
Model Abarth Fiat 1000 Coupé Record Monza Abarth Fiat 700 Abarth Monomille
Capacity 982 cc 696 cc 982 cc

Fiat 1000 Monomile
side camshaft with overhead valves (OHV) and pushrods

Fiat 100 series, straight 4 cyl, 4 stroke, petrol engine
698 cc
10.0:1
64 HP / 47 kW @ 7800 rpm
cast iron block with cast iron cylinder liners, aluminium alloy head
Twin Cam ("Bialbero")
2 x Weber 36 DCL4 or 2 x Weber 40 DCOE carburetors
12V 53Ah battery

Fiat 100 series, straight 4 cyl, 4 stroke, petrol engine
982cc
65.0 x 74.0 mm
90 HP @ 7200 rpm, 1000S: 99 HP
Twin Cam ("Bialbero")
2 x Weber 40 DCOE Twin-Choke carburetors

reat engine longitudinally placed, rear wheel drive
4-speed manual transmission
Fiat Tipo 112/122 rolling chassis
front suspension, Upper Trailing Arms w/Lower Transverse Leaf Spring, Hydrualic Dampers
rear suspension, Trailing Arms w/Coil Springs, Hydraulic Dampers
Worm & Sector steering, 2.75 turn lock to lock
drums all around 220mm diameter, or disc brakes all around 210mm diameter
wheelbase 2000 mm / 78.7"
front track 1150 mm / 45.3"
rear track 1160 mm / 45.7"
length 3470 mm / 136.6"
width 1350 mm / 53.1"
height 1140 mm / 44.9"
wheels, 3.5 x 12"
tires, 5.20×12" or 135 x 12"
535-570 kg
fuel tank, 45 lt, or 30 or 60 or 70 lt


Results in WSCC

Season

Group S
Car entry, chassis number Car number/ result
Buenos Aires Sebring Targa Florio Nurburgring Le Mans
Team 1000km 12h 1000km 24h
Abarth et Cie (850S) #49, clutch
Abarth et Cie (850S) #50, clutch
Abarth et Cie (700S) #60, eng ine
Guido Garufi/ Franco Tagliavia (850) #26, 36th
Scuderia Sant'Ambroeus (850) #63, 41st
Statistics
Works Starts/finishes 5/2 1/1 1/1 3/0
Drivers Team entries and car number
Abarth et Cie
Jacques Féret 49
Tommy Spychiger 49
Paul Condrillier 50
Jean Guichet 50
Giancarlo Rigamonti 60
Remo Cattini 60
Scuderia Sant'Ambroeus
Mario Poltonieri 63
Leo Levine 63

c-esp00115-5.jpg [https://www.ruotedasogno.com/]
Abarth Fiat 850 S '60
288acc5df920f860586510b4aef187a7.jpg Source
MC Spider Tipo 131
